Structured Cabling in Central Texas
Structured cabling is the permanent copper and fiber wiring, racks, patch panels and pathways that carry a building's network, phones and Wi-Fi. Engineer Austin designs and installs cabling for new construction, renovations and relocations, tests and documents every link, and designs the plant together with the network that will run on it.
From the telecom room to every jack
- Copper horizontal cabling from the telecom room to every work area, access-point location, phone, printer and wall display, in the category the network will need over the plant's service life.
- Fiber and copper backbone between telecom rooms, floors and buildings on the same property.
- Racks, cabinets and patch panels, installed, dressed and managed, with a rack-mounted UPS so the network rides through short power events.
- Labeling of every cable, jack, panel port and patch cord to one scheme that matches the port map we hand over.
- Certification testing of every installed link, with the results delivered as a written report rather than a verbal all-clear.
- New construction and build-outs, coordinated with the general and electrical contractors so pathways, sleeves, power and the telecom room are ready before the walls close.
- Renovations and relocations, in four phases: systems stabilized with a temporary network that keeps staff working; cabling, closets, conduit and UPS coordinated with the contractor; equipment relocated and recommissioned; and everything verified before staff return.
- Telecom-room clean-up. Tracing, re-terminating and labeling inherited cabling before a network is rebuilt on top of it.
- Design to recognized ANSI/TIA cabling standards, with drop counts and PoE load set by the switches, phones and Wi-Fi access points the plant will actually carry.
Best results start at the design phase
The least expensive time to get cabling and network infrastructure right is before construction starts. When we are brought in with your architect, general contractor and electrician while the drawings are still being drawn, cable drops, conduit and pathways, ceiling locations for access points, telecom-room space, power, cooling and grounding are all on the plans before work begins. Added after the walls close, the same work means opening walls, change orders and compromises. Bring us in at design and the cabling, the Wi-Fi design and the network equipment are planned together, so the right infrastructure is in place before construction begins.
From rough-in to finished rack
Schedule a cabling site assessment
Before a move, an expansion or a network upgrade, find out what the cabling you already have can carry. We assess cabling and telecom rooms from any installer, as a scheduled service with a written report you keep, quoted as a fixed fee or billed time and materials portal to portal, whichever works best for you. IT providers, installers and integrators can also book us for their own clients.
Existing cabling assessment
Every run traced and identified, labeling checked, cable category and condition recorded, and damaged, unlabeled or abandoned cabling listed, with a port map of what you actually have.
Certification testing
Existing links tested against their rated category, whoever installed them, so you know whether the cabling will support the speeds, PoE and access points you are planning.
Telecom room and rack review
Racks, patch panels, cable management, power and UPS, grounding and bonding, cooling and physical security, with numbered findings and a fix list ranked by risk.
Move and expansion readiness
For a new lease or an added floor: what can be reused, what must be replaced and what the space still needs, before you sign or the build-out is priced. Before move-in, we review power and UPS, rack and closet layout, and physical security of the communication rooms.
Design review for new construction
A review of the drawings before construction starts, so drops, pathways, conduit, telecom-room space and power are on the plans, together with the Wi-Fi design.
Assessments for other providers
MSPs, installers and integrators can book an assessment or certification test for a client site. You keep the client relationship; we deliver the measurements and the report.
Survey, design, install, document
Survey
We walk the space or read the construction drawings, count the drops, locate the telecom room and pathways, and note which existing cabling can be kept. Cabling and network design are done together, so drop counts reflect the switches and access points that will actually be installed.
Design and propose
You receive a drawing of drop locations, a rack elevation and backbone routes with a fixed-fee quotation. Cabling is project work, billed separately from the Managed Service Program, and nothing is ordered before your written approval.
Install and test
Our installation technicians pull, terminate, dress and label the plant, then test every link and record the result. A link that fails is corrected before the report is issued. Licensed electrical work incidental to the job is subcontracted and disclosed in advance.
Document and hand over
The test report, port map and as-built drawing are delivered with the finished room. If the network is under our management, the same documents become the baseline for every later move, add and change.
Handed over with the finished room
- Certification test results for every installed link, in writing.
- A port map and cable schedule that match the labels on the wall and in the rack.
- An as-built drawing of drop locations, backbone routes and the rack elevation.
- A clean, labeled telecom room with cable management and UPS power in place.
- A fixed-fee quotation up front, and we correct our own mistakes on the finished work at no charge, under the terms of our written agreement.
- Records that stay with the building, so the next contractor or tenant is not starting from zero.
How AI speeds this up for you
The as-built drawing, port map and test-report summary are generated from labeled photographs and the tester's export files with AI assistance, then checked by the technician who ran the tests before anything is issued. You receive a complete record on handover day rather than weeks later, at the same fee. How we use AI.
Designed with the network it carries
One firm for the plant and the network
Cabling is the one part of a network that is expensive to change once the walls are closed, so it deserves a design rather than a count of jacks.
Pathways, counts and terminations are set in a basis of design to recognized cabling standards, with criteria for growth and PoE load, and the as-built you receive is field-verified test data rather than a vendor sketch. Our installation checklist is revised after every job: a pathway or termination problem found in the field is written up and designed out of the next one.
Engineer Austin is Texas Registered Engineering Firm F‑15739; cabling is designed on engineering principles under a licensed engineering firm, by the same people who specify your firewall, switches and Wi-Fi, and a licensed Professional Engineer is accountable for the recommendation.
Who this is for
Offices and clinics moving into new or renovated space, cities and districts building or remodeling a facility, multi-site businesses standardizing their telecom rooms, and any organization whose current closet has become a tangle nobody wants to touch.
Cabling pairs naturally with our network engineering, hosted VoIP and fiber services.
Structured cabling, answered plainly
Is cabling included in the Managed Service Program?
No. Structured cabling, racks and physical wiring are project work, quoted as a fixed fee and billed separately from the monthly program. Connectivity troubleshooting on existing cabling is part of normal support for managed sites. Keeping the two apart means your monthly fee is not carrying the cost of a build you may never need.
Can you cable a building that is still under construction?
Yes, and the earlier the better. Ideally we are involved from the design phase, working from the drawings with your architect, so pathways, sleeves, telecom-room size and power are planned before construction starts; at the latest, before drywall, while they can still be adjusted. We coordinate drop locations and conduit with the general and electrical contractors, pull and terminate at the right stage, and test and label the plant before the network equipment arrives.
Do you test the cables after installation?
Yes. Every installed link is tested and the results are delivered in a written report. A link that fails is corrected before the report is issued. The test record, the port map and the as-built drawing are handed over together, so any later problem can be traced to a specific jack, panel port and cable rather than guessed at.
Should the run between our buildings be copper or fiber?
It depends on distance, the ground between the buildings and what the link must carry. Copper has a hard distance limit and can carry lightning and ground-potential problems between structures. Fiber has neither issue and is usually the right choice for a backbone run. Where trenching is impractical, a point-to-multipoint wireless link is a third option we can design.
Can you clean up the wiring closet we already have?
Yes. We trace and label what is there, re-terminate or replace what is damaged, add a rack, patch panels, cable management and a UPS as needed, and test every link we touch. The clean-up is usually scheduled alongside a network remediation so the room is rebuilt once, not twice, and the port map we leave behind is accurate.
Who handles the electrical work?
Low-voltage cabling, racks and network equipment are installed by our own technicians. Line-voltage work such as new circuits or receptacles for the telecom room is performed by a licensed electrical contractor. We coordinate that work, disclose it in the quotation and remain the single point of accountability for the project.
Start with a written assessment.
Tell us what you have and what is not working. Someone from our team, not a salesperson, replies within one business day by email or phone, and brings in our engineer when your request needs one. The assessment report is yours to keep whether or not you buy anything.
